The Bay Creek 145 | Coastal Craftsman Home Plan - 3 Bed, 4,549 SF
Key Specs
Beds
3
Baths
2.5
Heated sq. ft.
4,549 sq. ft.
Floors
2
Garage
Yes
Master Location
2nd Floor
Floor 1 sq. ft.
2,434 sq. ft.
Floor 2 sq. ft.
2,033 sq. ft.
Floor 3 sq. ft.
-
Floor 4 sq. ft.
-
Width
49' 0"
Depth
50' 0"
Product Details
The Bay Creek 145 is an impressive coastal Craftsman home plan that combines traditional Southern charm with a carefully thought-out, modern layout. With 4,549 square feet of heated living space, this plan features generous gathering areas, elevated living spaces, and flexible zones that make it ideal for coastal estates, waterfront lots, or homesites with expansive views.
Distinctive Layout for Everyday Living and Entertaining
On the ground floor, all bedrooms are conveniently located for privacy and ease, creating comfortable retreats for family members and guests alike. A standout recreation room on this level features a coffered ceiling, cozy fireplace, and wet bar, making it a perfect spot for media nights, celebrations, or casual entertaining.
Open, Vaulted Upper Living Spaces
The second level is designed to elevate everyday living. Here, the family room opens under vaulted ceilings and flows seamlessly onto a spacious deck — ideal for outdoor gatherings or relaxing in the fresh coastal air. Adjacent to this, a bright sunroom surrounded by windows invites natural light and creates a serene indoor-outdoor connection.
Master Suite Retreat and Bonus Space
Also located on the upper level, the master suite offers a private retreat with a generously sized bathroom and well-planned circulation. For even more flexibility, a bonus space above the garage provides opportunities for future expansion, hobbies, or additional living space tailored to your lifestyle.
Floor Plans
What's Included
-
Title sheet
-
Standard notes page
-
Foundation
-
First floor
-
Second floor (if applicable)
-
Roof plan
-
Elevations (all 4 sides)
-
General Notes and Details Pages
**A Required Release Form will be sent shortly after purchase, and must be signed and emailed back, in order to receive purchased plans**
What's Not Included
-
Architectural or Engineering Stamp - handled locally if required
-
Site Plan - handled locally when required
-
Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
-
Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
-
Energy calculations - handled locally when required
-
Electrical Plans and Full Building sections
