Welcome to The Graydon 4 197, a smart, space-efficient 4-bedroom, 2.5-bath narrow-lot home plan from RBA Home Plans — perfect for urban infill lots, compact suburban sites, or infill neighborhoods where lot width is limited. With just 18′-10″ width and 50′ depth, this 1,610 sq ft two-story design delivers a thoughtfully configured footprint that maximizes livability without sacrificing comfort.
Inside, this plan features:
A modern, open-concept main floor layout designed for efficient flow and flexible living
Four comfortable bedrooms and 2.5 baths, ideal for small families, empty-nesters, or downsizing buyers
A footprint optimized for narrow lots, saving on land costs while delivering full-size rooms and functional living spaces
As part of RBA Home Plans’ Narrow Lot collection, Graydon 164 demonstrates how good architecture can turn lot constraints into an opportunity — offering homeowners a stylish, code-compliant plan that’s easy to build on compact parcels.
What's Included
-
Title sheet
-
Standard notes page
-
Foundation
-
First floor
-
Second floor (if applicable)
-
Roof plan
-
Elevations (all 4 sides)
-
General Notes and Details Pages
**A Required Release Form will be sent shortly after purchase, and must be signed and emailed back, in order to receive purchased plans**
What's Not Included
-
Architectural or Engineering Stamp - handled locally if required
-
Site Plan - handled locally when required
-
Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
-
Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
-
Energy calculations - handled locally when required
-
Electrical Plans and Full Building sections
Key Specs
Bedrooms
4
Floor 1 sq. ft.
718 sq. ft.
Bathrooms
2.5
Floor 2 sq. ft.
892 sq. ft.
Total Heated sq. ft.
1,610 sq. ft.
Floor 3 sq. ft.
-
Floors
2
Floor 4 sq. ft.
-
Garage
Yes
Location of Master
2nd Floor
Width
18' 8"
Depth
50' 0"
